Sealed Structure Thermal Chamber Prevents Medium From Evaporating Thermal Chamber

The thermal chamber is suitable for examining the ability of the whole machine, components, parts and other components to withstand sharp changes in temperature. The temperature impact test can understand the impact of the test sample once or repeatedly due to temperature changes. The main parameters affecting the temperature change test are the high and low temperature values in the range of temperature change, the holding time of the sample at high and low temperature, and the number of cycles of the test, etc.

• Test volume:2.6 litres
• Sample chamber size:120×120×150mm (WIDTH × depth × height)
• Inner Size of the liquid chamber:250×350×400mm (WIDTH × depth × height)
• Exterior size of the chamber:1000mmx17500mmx1900mm

• Fluorocarbon oil, liquid test medium

• Power supply AC380V±10%,50Hz±1

• Cooling mode Water-cooled (refrigerating unit)

• Cryogenic liquid impact test range: -65℃ ~ 0℃
• Low temperature liquid impact test range: -65℃ ~ 0℃
• High temperature liquid impact test range: +70℃ ~ +150℃
• Temperature fluctuation: ±0.3℃ ~ ±1.0℃
• Temperature uniformity: ±0.5℃ ~ ±2.0℃
• Temperature deviation: < ±2℃
